N2XY PVC Wire
N2XY PVC Wire, PVC cable, control cable, power control cable

Code: N2XY
Standards: TS IEC 60502, IEC 502, VDE 0276-603, BS 6346
Construction:
  1- Solid or Stranded Copper Conductor
  2- XLPE insulation(cross-linked PE).
  3- PVC filling
  4- PVC Outer Sheath
Application:
  Preferably for installation indoors in cable ducts and in industrial plants or switching stations, under ground installation with additional protection where mechanical damage is unexpected.
Technical Data :
  Max. operating temperature 90 ℃
  Short circuit temperature 250 ℃

Num. of Cores and Nominal Cross Section No. of Wires & Diameter Thickness of Insulation Thickness of Sheath Conductor DC Resistance at 20℃ Approx. Total Weight Max. Current Carrying Capacity at 30℃
No.×mm2 No.×mm mm mm Ω/km kg/km Pip A Air A
 2 × 1.5    1.35    0.7    1.8    12.1    137    37    26
 2 × 2.5    1.73    0.7    1.8    7.41    186    49    36
 2 × 4    2.19    0.7    1.8    4.61    215    64    49
 2 × 6    2.68    0.7    1.8    3.08    272    79    63
 2 × 10    7 × 1.33    0.7    1.8    1.83    381    106    86
 2 × 16    7 × 1.66    0.7    1.8    1.15    534    137    115
 3 × 1.5    1.35    0.7    1.8    12.1    154    31    23
 3 × 2.5    1.73    0.7    1.8    7.41    195    40    32
 3 × 4    2.19    0.7    1.8    4.61    254    52    42
 3 × 6    2.68    0.7    1.8    3.08    325    64    54
 3 × 10    7 × 1.33    0.7    1.8    1.83    496    86    75
 3 × 16    7 × 1.66    0.7    1.8    1.15    671    112    100
 4 × 1.5    1.35    0.7    1.8    12.1    177    31    23
 4 × 2.5    1.73    0.7    1.8    7.41    228    40    32
 4 × 4    2.19    0.7    1.8    4.61    301    52    42
 4 × 6    2.68    0.7    1.8    3.08    392    64    54
 4 × 10    7 × 1.33    0.7    1.8    1.83    619    86    75
 4 × 16    7 × 1.66    0.7    1.8    1.15    848    112    100
 5 × 1.5    1.35    0.7    1.8    12.1    202    31    23
 5 × 2.5    1.73    0.7    1.8    7.41    257    40    32
 5 × 4    2.19    0.7    1.8    4.61    350    52    42
 5 × 6    2.68    0.7    1.8    3.08    463    64    54
 5 × 10    7 × 1.33    0.7    1.8    1.83    745    86    75
 5 × 16    7 × 1.66    0.7    1.8    1.15    1066    112    100
