H07V2-K PVC Wire
H07V2-K PVC Wire, PVC cable, control cable, power control cable

Code: H07V2-K
Standards: TS 9758, IEC 227, VDE 0281, BS 6004
Construction:
  1- Flexible Copper Conductor
  2- PVC insulation
Application:
  For protected installation in equipment and lighting fitting.
  Also for in conduit. on and under plaster.
Technical Data :
  Max. operating temperature 90 ℃
  Short circuit temperature 160 ℃

Nominal Cross Section No. of Wires & Diameter Thickness of Insulation Mean Overall Diameter Conductor DC Resistance at 20℃ Approx. Total Weight Max. Current Carrying Capacity at 30℃
mm2 No.×mm mm min max Ω/km kg/km Pip A Air A
 1.5    27 × 0.25    0.7    2.8    3.4    13.3    21.0    15    24
 2.5    45 × 0.25    0.8    3.4    4.1    7.98    32.0    20    32
 4    50 × 0.30    0.8    3.9    4.8    4.95    48.0    25    42
 6    75 × 0.30    0.8    4.4    5.3    3.30    68.0    33    54
 10    73 × 0.40    1.0    5.7    6.8    1.91    113    45    73
 16    119 × 0.40    1.0    6.7    8.1    1.21    174    61    98
 25    182 × 0.40    1.2    8.4    10.2    0.780    282    83    129
 35    252 × 0.40    1.2    9.7    11.7    0.554    378    103    158
 50    364 × 0.40    1.4    11.5    13.9    0.386    543    132    198
