H07V-K PVC Wire
H07V-K PVC Wire, PVC cable, control cable, power control cable

Code: RV,H07V-K, NYAF
Standards: IEC227, BS 6004, VDE0281
Construction:
  1- Flexible Copper Conductor
  2- PVC insulation
Application:
  For protected installation in equipment and lighting fitting. Also for in conduit, on and under plaster
Technical Data :
  Max. operating temperature 70 ℃
  Short circuit temperature 160 ℃

Nominal Cross Section No. of Wires & Diameter Thickness of Insulation Mean Overall Diameter Conductor DC Resistance at 20℃ Approx. Total Weight Max. Current Carrying Capacity at 30℃
mm2 No.×mm mm min max Ω/km kg/km Pip A Air A
1.5 27×0.25 0.7 2.8 3.4 13.3 21.0 15 24
2.5 45×0.25 0.8 3.4 4.1 7.98 32.0 20 32
4 50×0.30 0.8 3.9 4.8 4.95 48.0 25 42
6 75×0.30 0.8 4.4 5.3 3.30 68.0 33 54
10 73×0.40 1.0 5.7 6.8 1.91 113 45 73
16 119×0.40 1.0 6.7 8.1 1.21 174 61 98
25 182×0.40 1.2 8.4 10.2 0.780 282 83 129
35 252×0.40 1.2 9.7 11.7 0.554 378 103 158
50 364×0.40 1.4 11.5 13.9 0.386 543 120 198
